| Alarm indication: | Signal to control panel |
|---|---|
| Battery: | CR123A 3 V |
| Battery life: | .max. 3 years |
| Colour: | Brown |
| Cooperation: | Satel MICRA |
| Current consumption: | 18 mA |
| Detection: | Glass break sensor |
| Dimensions: | 25 x 111 x 28 mm |
| Environmental class en 50130-5: | II |
| Frequency band: | 433.05 MHz ... 434.79 MHz |
| Operating temperature: | -10 °C ... 55 °C |
| Permissible relative ambient humidity: | 93 ± 3 % |
| Producer / brand: | SATEL |
| Radio communication range (in open area): | .max. 200 m |
| Scales: | 0.04 kg |
| Selected features: | Breaking plain, laminated, tempered glass Test mode stepless sensitivity adjustment |
| Warranty: | 2 years |
The sensor sounds an alarm if it registers a low-frequency signal (impact sound) and a high-frequency signal (the sound of breaking glass)A low-frequency sound wave caused by an impact causes the sensor to analyze the high-frequency channel
High-frequency channel analysis takes 4 secondsIf during this time there is a high-frequency sound, that is, the sound of breaking glass, the sensor will trigger an alarm
