VIDEO SPLITTER RV-16/32-UHD/R19

€182.83

Shipping from warehouse: ⁨D4⁩

Estimated shipping: Tue, Dec 24 - Fri, Dec 27

14 days returnUnconditional return policy

Availability:: moderate quantity
Brand:: Delta
Product code:: RV-16/32-UHD/R19 / 5902887056383

Specification

Amplification::	0 dB
Current consumption::	120 mA @ 12 V DC
Dimensions::	490 x 44 x 38 mm
Entrance protection::	ESD, IEC 61000-4-2, ±30kV contact, ±30kV airLightning, IEC 61000-4-5, 12A (tP=8/20μs)
Housing type::	1 U Rack 19"
Input impedance::	75 Ω
Manufacturer / brand::	DELTA
Number of inputs::	16 pcs. BNC
Number of outputs::	32 pcs. BNC
Operating band::	0 ... 120 MHz (-3dB)
Output impedance::	75 Ω
Output protection::	ESD, IEC 61000-4-2, ±30kV contact, ±30kV airLightning, IEC 61000-4-5, 12A (tP=8/20μs)
Power::	7 ... 26 V DC (no power supply included)
Scales::	0.44 kg
Standard::	AHD / HD-CVI / HD-TVI - 8 Mpx 4K UHD, CVBS - PAL, NTSC
Warranty::	5 years

The RV-16/32-UHD/R19 splitter consists of 16 independent two-output video signal splittersModern design of the device allows cooperation with all standards commonly used in CCTV systems, operating in the band up to 120MHzIt means that the signal can be separated in the maximum resolution: AHD - 8Mpx, HD-CVI - 8Mpx, HD-TVI - 8Mpx, CVBS - 960H

The device is adapted to continuous operation, in enclosed spaces

Appropriate distances between sockets allow you to freely tighten any BNC plug with your fingers

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
