Victron Energy Orion-Tr Smart 24/12-30 non-isolated charger
€263.15
Shipping from warehouse: A3
Estimated shipping: Mon, Nov 25 - Thu, Nov 28
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Victron Energy
- Product code:
- ORI241236140 / 8719076048978
Share this product:
Specification
| Bluetooth: | Yes |
|---|---|
| Built-in display: | No |
| Conductor cross section: | 16 mm² |
| Dc battery voltage: | 12 / 24 V |
| Dedicated application: | VictronConnect |
| Depth: | 130 mm |
| Easy to install: | Yes |
| Efficiency: | 88% |
| Fernbedienung: | Y |
| Heat protection: | Y |
| Height: | 70 mm |
| Input voltage range: | 20 - 35 V |
| International protection (ip) code: | IP43 |
| Led indicators: | Yes |
| Nominal output voltage: | 12,2 V |
| Operating temperature (t-t): | -20 - 55 °C |
| Output current: | 30 A |
| Output power at 25°c: | 430 W |
| Output power at 40°c: | 360 W |
| Parallel connection possible: | Unlimited number of devices |
| Product colour: | Blue |
| Product type: | Loader |
| Programmable: | Yes |
| Remote on/off switch: | Yes |
| Short circuit protection: | Yes |
| Specific features: | 3-stage charging algorithm |
| Supported battery type: | Lithium, Lead-acid |
| Weight: | 1.8 kg |
| Width: | 186 mm |
