Reliable technical solutions
Well-thought-out technical solutions make it possible to fasten and unfold components with a force of up to 2,000 N using only one hand.
Intelligent release mechanism
The intelligent release mechanism allows you to easily and quickly move the fixed arm from the clamping function to the expansion function without the use of additional tools.
Shifted handle
The ergonomic two-component plastic handle with closing lever is placed behind the rail, allowing for a comfortable grip and high force during fastening.
Protective caps
Protective caps protect the element during operation and guarantee a safe grip.
Description:
- EZS: Clamping force up to 2,000 N
- Switch to the expansion function without the use of additional tools thanks to the intelligent release mechanism in the fixed arm
- Ergonomic, two-component plastic handle located behind the rail
- One-handed operation without the use of force
- In a package with a pendant
Technical data:
- symbol - EZS45-8
- working range - 450 mm
- outreach - 80 mm
- max. external capacity - 170-660 mm
- rail - 19x6 mm
- weight - 0,93 kg
- application: wood, plastics, delicate materials
