Twist drill HSS Co5, cylindrical shank, long execution, DIN 340, type GU 500
Material: ground profile, wide flutes. Lateral approach angle larger than normal, with a special profile.
Application: designed in particular for various grades of cast iron, plastics and non-ferrous metals.
Twist drill DIN340 HSSETiN,type GU,4,5mm GÜHRING
€14.75
Shipping from warehouse: B6
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- GÜHRING
- Product code:
- 9055370045000 / 4049844046757
Share this product:
Specification
| Aluminium > 8% silicon: | 50 |
|---|---|
| Cast iron gg/gts: | 26 |
| Ggg cast iron: | 20 |
| Inox austenite.: | 8 |
| Inox ferrite./martenz.: | 13 |
| Ø h7: | 4.5 mm |
| Overall length: | 126 mm |
| Spiral length: | 82 mm |
| Steel < 1000 n/mm2: | 25 |
| Steel < 1400 n/mm2: | 12 |
| Steel < 700 n/mm2: | 28 |
| Steel < 700 n/mm2 f: | 0.125 mm/rev. |
