Twist drill HSS Co5, cylindrical shank, long execution, DIN 340, type GU 500
Material: ground profile, wide flutes. Lateral approach angle larger than normal, with a special profile.
Application: designed in particular for various grades of cast iron, plastics and non-ferrous metals.
Twist drill DIN340 HSSETiN,type GU,3,2mm GÜHRING
€13.05
Shipping from warehouse: B6
Estimated shipping: Wed, Dec 25 - Mon, Dec 30
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- GÜHRING
- Product code:
- 9055370032000 / 4049844046887
Share this product:
Specification
| Aluminium > 8% silicon: | 50 |
|---|---|
| Cast iron gg/gts: | 26 |
| Ggg cast iron: | 20 |
| Inox austenite.: | 8 |
| Inox ferrite./martenz.: | 13 |
| Ø h7: | 3.2 mm |
| Overall length: | 106 mm |
| Spiral length: | 69 mm |
| Steel < 1000 n/mm2: | 25 |
| Steel < 1400 n/mm2: | 12 |
| Steel < 700 n/mm2: | 28 |
| Steel < 700 n/mm2 f: | 0.125 mm/rev. |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
