Twisting drill, cylindrical shank
Design: right-handed, with precise top grinding. Lateral approach angle normal, core thickness greater than normal, core convergence normal.
Application: designed especially for alloy and non-alloy steels, cast iron with a strength exceeding 800 N/mm2, cold and hot steels, bearing steels, high-alloy steels, steels for heat conditioning and carburizing.
Twist drill DIN338 HSSEtype N,4,20mm GÜHRING
€7.00
Shipping from warehouse: B6
Estimated shipping: Fri, Dec 20 - Mon, Dec 23
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- GÜHRING
- Product code:
- 9003050042000 / 4031093093217
Share this product:
Specification
| Cast iron gg/gts: | 30 |
|---|---|
| Execution: | Surface tempered in water vapour |
| Ggg cast iron: | 24 |
| Inox austenite.: | 14 |
| Inox ferrite./martenz.: | 18 |
| Ø h7: | 4.2 mm |
| Overall length: | 75 mm |
| Spiral length: | 43 mm |
| Steel < 1000 n/mm2: | 30 |
| Steel < 1400 n/mm2: | 16 |
| Steel < 700 n/mm2: | 40 |
| Steel < 700 n/mm2 f: | 0.063 mm/rev |
