SPARTA HIRRO External LTE antenna VHF-UHF SPARTA HIRRO is used to receive digital terrestrial television.
This antenna is equipped with an LTE filter that eliminates interference with LTE signals and has the ability to receive TV channels in the VHF and UHF bands.
This antenna has an innovative solution, namely a dipole equipped with BYPASS AMPLIFIER. It is a dipole with a special design, which has a built-in symmetrizer and amplifier. This means that this antenna can be a passive antenna or an active antenna without additional changes.
Thanks to this, you will avoid replacing the symmetrizer with an amplifier.
However, a 12V/24V power supply is required to work as an active antenna (not included).
The symmetrizer built into the dipole has a gain of 17 dB, while the amplifier allows signal gain up to 35 dB.
This antenna is made of high quality materials and its innovative way of folding the CLICK-CLACK antenna does not require any tools.
TECHNICAL PARAMETERS:
Channel reception: VHF 5-12, UHF 21-60
Number of elements: 21
Bandwidth: 174-230MHz and 470-790MHz
Energy gain:
passive VHF antenna 6-9 dB, UHF 11-17 dB
active antenna VHF 10-15 dB, UHF 26-35 dB
Front/rear ratio: VHF 10-17 dB, UHF 15-24 dB
Vertical-horizontal polarization: H60o/V65o, H45o/V50o
Impedance: 75Ω
F connector
Length: 1310 mm
