Tuner GTMedia Freesat 8X COMBO DVB-S2/S2X/T2/C WiFi emulator CCCam, NewCamd
- Fully compatible with TV standard: DVB-S/S2/S2X/T/T2/C (SCPC and MCPC reception of channels in the C-band Ku), MPEG-2/4 and H.265 HEVC
- channel search: support for automatic TV search for new added transponders
- Memory for over 6000+ TV channels (TV and radio channels)
- PVR recording: record one TV channel and watch another on the same TP at the same time, channel editing function (favorite, move, block, skip, delete, rename, search, sort)
- FAV Favorites: Create up to 31 different favorite channel groups
- OSD: 32-bit on-screen menu with anti-flicker function
- OSD setting: support OSD timeout and transparency, subtitle display
- Other settings: set different settings for normal work
- Ctrl: parental control for channels
- EPG: full 7-day electronic programme guide (EPG)
- Time settings: time set automatic and manual GMT offset, daylight saving time support
- Timer: 5 event timers
CA Card Slot - Universal Smart Card Reader
- Nagra CAID 183E (for 13E Italy Tivusat)
- Conax CAID 0B01 (for 13E Poland TNK)
- Seca CAID 0100 (for 13E Polska Cyfra+)
- Viacess CAID 0500 (for 16E Croatia OIV)
- CryptoWorks CAID 0D98 (for 19.2E Austria ORF ICE..)
- Seca CAID 0100 (for 19.2E/23.5E Dutch channel Digitaal)
- Conax CAID 0B00 (for cable)
The decoder supports the new compression: H.265 HEVC which takes up less bandwidth than H.264
The new H.265 HEVC 10bit technology uses advanced technology to charge and play more HD videos faster.
SAT to IP - Screen Mirroring satellite TV on mobile devices
- GTShare smartphone app
- Distribution of live satellite content via IP network on a mobile device
- TV everywhere in the house on the same IP network
- Watch another program on your smartphone at the same time while watching TV on tv
Technical parameters:
- CPU frequency: 770MHz dual-core HEVC 10Bit
- Flash memory: 64MB SPI Flash
- DDR2 memory: 1G bit RAM
- Demultiplexer: ISO/IEC 13818-1
- Input bitrate: max. 100Mbit/s
- H.265 HEVC, H.264 BP,MP and HP @ L3/L4.1/L4.2 MPEG-4
- PAL/NTSC: automatic PAL/NTSC conversion
- Aspect ratio: Auto, 16:9, 4:3 Pan & Scan, 4:3
- Video resolution: 1080P, 1080I, 720P, 576P, 480P, 576I, 480I
- HDMI color space: RGB, YUV422, YUV444, Auto
- WiFi: built-in WiFi 2.4G IEEE 802.1.1b/g/n
- Frequency range: 950~2150MHz for DVB-S/S2/S2X baseband demodulator
- LNB: DiSEqC 1.0/1.1/1.2/USALS
- Support Unicable, 13/18V DC@400mA MAX, 22KHz ± 0.4KHz(0.6V ± 0.2V)ton, overload protection
- Input level range: -80dBm ~ -20dBm (average power)
- DVB-S QPSK,DVB-S2 QPSK/8PSK/16APSK/32APSK
- DVB-S2X QPSK/8PSK/16APSK/32APSK/64APSK
- Online Video (Youtube, Youporn, Hotstar)
- Internet TV player: IPTV M3U
- SAT streaming to Gtplayer, DLNA
- Built-in softcam emulator: CCCAM, NEWCAM, MGCAM;
- Support page: www.freesat.cn
Technical data:
- Brand: GTMEDIA
- Model: X8 COMBO
- Material: Metal
- Color: Black
- Power consumption: DC 12V 1.5a
- Size: 170x116x33mm
- Remote control size: 178x50x12mm
- Weight: 344g
- Package size: 260x162x55mm
- Package weight: 686g
