TSCHORN 2D edge sensor, acoustic and optical

€137.81
Shipping from warehouse: ⁨B6⁩
Estimated shipping: Wed, Nov 6 - Mon, Nov 11
14 days returnUnconditional return policy
Availability:
large quantity
Brand:
TSCHORN
Product code:
001122000 / 4260192270490

Specification

Execution:2D
Overall length:119 mm
Shank diameter:20 mm

Edge sensor, optical/acoustic

Design: hardened and precisely ground, with red LED glowing. Delivery in a plastic pouch.
Application: for measurements on drills and milling machines as well as machining centers with an accuracy of 0.01 mm. For external internal centering. Touching the edge of the element, the indicator lights up and triggers a beep. The zero line is reached taking into account the radius of the measuring sphere. The ball at the end of the sensor fixed with a spring moves away when it hits over the edge of the element, which protects the sensor from damage.
Scope of delivery: edge sensor with A23 battery.
