| -10 °c ... 40 °c: | Operating temperature: |
|---|---|
| 0.05 kg: | Scales: |
| 1: | Number of relay outputs: |
| 1 x no/nc: | Egress: |
| 10 ... 14 vdc: | Power: |
| 10 a (max), 30 v dc / 250 v ac (max): | Contact load capacity: |
| 100 x 43 x 23 mm: | Dimensions: |
| 2 years: | Warranty: |
| 51 ma (max): | Current consumption: |
| Eeprom non-volatile memory, time setting range 1 s ... 99 h, led signalling: | Selected features: |
| Pulsar: | Manufacturer / Brand: |
AWZ-516 enables the implementation of 1 out of 8 time-logic programs
The device can be used to extend short pulses controlling e.g. the operation of bolts, solenoid valves, bistable control, as well as to make a transition in access control projects, with logical dependencies on the status: controller, door opening sensor (reed switch), output button, etc.
