Thermaltake Toughpower SFX 450
This product is not available
- Availability:
- expected delivery
- Brand:
- Thermaltake
- Product code:
- PS-STP-0450FNFAGE-1 / 4713227527798
Share this product:
Specification
| 80 plus certification: | 80 PLUS Gold |
|---|---|
| Ac input frequency: | 50/60 Hz |
| Ac input voltage: | 100 - 240 V |
| Atx power connector (24-pin): | Y |
| Combined power (-12v): | 3.6 W |
| Combined power (+12v): | 450 W |
| Combined power (+3.3v): | 100 W |
| Combined power (+5v): | 100 W |
| Combined power (+5vsb): | 12.5 W |
| Cpu power connector (4+4 pin): | Y |
| Depth: | 100 mm |
| Fan diameter: | 9 cm |
| Fan location: | Rear |
| Height: | 63.5 mm |
| Hold time: | 16 ms |
| Input current: | 10 A |
| Max output current (-12v): | 0.3 A |
| Max output current (+12v): | 37.5 A |
| Max output current (+3.3v): | 20 A |
| Max output current (+5v): | 20 A |
| Max output current (+5vsb): | 2.5 A |
| Mean time between failures (mtbf): | 100000 h |
| Motherboard power cable length: | 30 cm |
| Motherboard power connector: | 24-pin ATX |
| Number of fans: | 1 fan(s) |
| Number of sata power connectors: | 3 |
| On/off switch: | Y |
| Operating relative humidity (h-h): | 20 - 85% |
| Operating temperature (t-t): | 5 - 40 °C |
| Pci express power connectors (6+2 pin): | 2 |
| Peak power: | 540 W |
| Peripheral (molex) power cable length: | 150, 300 |
| Peripheral (molex) power connectors (4-pin): | 2 |
| Power factor correction (pfc) type: | Active |
| Power supply unit (psu) form factor: | SFX |
| Product colour: | Black |
| Purpose: | PC |
| Safety: | CE/cTUVus/TUV/FCC/BSMI/EAC/CCC/S-Mark/C-TICK |
| Sata power cable length: | 150, 300 mm |
| Storage relative humidity (h-h): | 10 - 95% |
| Storage temperature (t-t): | -40 - 55 °C |
| Supported motherboard form factors: | ATX |
| Total power: | 450 W |
| Weight: | 840 g |
| Width: | 125 mm |
