| Current efficiency of the power supply:: | 12.5 A |
|---|---|
| Dimensions:: | 159 x 97 x 30 mm |
| Manufacturer / brand:: | Delta Electronics |
| Number of outputs:: | 2 pcs. |
| Operating temperature / relative humidity:: | -10 °C ... 70 °C / 5 % ... 95 % |
| Output voltage adjustment:: | 11.4 ... 13.5 volts |
| Output voltage:: | 12 VDC |
| Power supply type:: | Pulse |
| Power supply:: | 150 watts (Printing) |
| Scales:: | 0.36 kg |
| Security:: | Short-circuit Overload Thermal Surge Protector |
| Supply voltage:: | selected by 100 V switch ... 120 V AC, 200 V ... 240 V AC |
| Warranty:: | 5 years |
Dual-pair output power supply
Special attention should be paid to the proper cooling of the power supply during operation! In rack cabinets and poorly ventilated places, we recommend using the following elements together with the power supply: A19-W12 fan and FR-1 rotation controller
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
