| Current efficiency of the power supply:: | 5 A (total) 2 A / Single output - Polymer fuse |
|---|---|
| Dimensions:: | 148 x 55 x 37 mm |
| Frequency range:: | 50 / 60 Hz |
| Housing type:: | Plastic |
| Number of outputs:: | 4 pcs. |
| Operating temperature:: | - 10 °C ... 50 °C |
| Output voltage:: | 12 VDC |
| Power supply type:: | Pulse |
| Power supply:: | 60 watts |
| Scales:: | 0.23 kg |
| Security:: | Overload Short Circuit Overvoltage Thermal |
| Selected features:: | Output voltage regulation : 11.8 V ... 15 V DC Wall Mountable Enclosure |
| Supply voltage:: | 100 ... 240 V AC |
| Warranty:: | 2 years |
Power supply designed to work with CCTV cameras
Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum currentSpecial attention should be paid to the proper cooling of the power supply during operation!
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
