SWITCHING POWER SUPPLY 12V/10A/PA18

€38.94
Shipping from warehouse: ⁨D4⁩
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
Availability:
moderate quantity
Product code:
12V/10A/PA18 / 5902887030017

Specification

Connector type::Cable clamps
Current efficiency (total)::10 A
Dimensions::315 x 207 x 55 mm
Housing type::Metal, wall mounted
Input voltage::230 VAC
Number of outputs::18
Output voltage adjustment::11  ... 13 volts
Output voltage::12 VDC
Power supply type::Pulse
Power::120 W (instantaneous 145W)
Scales::1.95 kg
Warranty::2 years

The power supply has an aesthetic, solidly made metal housingThe operation of the power supply is signaled by an LED placed in the housingThe power supply is stabilized and supports up to 18 devices with max. load of 560mA eachever current path is protected by a polymer fuse and has an LED indicating the voltage at a given output

Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum currentSpecial attention should be paid to the proper cooling of the power supply during operation!

Remark! The power supply does not have a built-in current limit

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
