AXON-MULTINET-4 is a multi-channel device designed for surge protection of devices connected to Ethernet networks 10/100/1000 Mbps, such as: network cards, hubs, switches, routers, etc. The device consists of 8 independent channels (I/O), within which 4 pairs of UTP cables are protected with charge transfer to the ground
SURGE ARRESTER AXON-MULTINET-4 ETHERNET
€106.47
Shipping from warehouse: D4
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Product code:
- AXON-MULTINET-4 / 5904743333607
Share this product:
Specification
| ≤ 40 v - 1 kv/μs [c3]: | Surge protection level (line-to-line): |
|---|---|
| ≤ 600 v - 1 kv/μs [c3]: | Line-to-ground protection voltage: |
| 1-2, 3-6, 4-5, 7-8: | Protected wire pairs: |
| 10 / 100 / 1000 mbps: | Baud: |
| 20 a - 10/1000 μs [c3]: | Nominal discharge current (line-ground): |
| 5 volts: | Voltage: |
| 52 cm: | Ground wire length: |
| 6 volts: | Maximum voltage: |
| 8 x rj-45 jack - shielded (8p8c) ( 4 inputs, 4 outputs ): | Socket Type: |
| Compliant with pn-en61643-21: | Protection parameters: |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
