Submersible pump for deep well MSW 10800 L/h up to 96 m

€287.26
Shipping from warehouse: ⁨H1⁩
Estimated shipping: Mon, Nov 25 - Tue, Nov 26
14 days returnUnconditional return policy
Availability:
large quantity
Brand:
MSW
Product code:
10060174 / 4250928684400

Specification

Sku:1009063
10060174 Efficient submersible submersible pump MSWo power 2200 Speed 2850 rpm 10800lires per hour96 mhermetically closed stainless steel control box equipped with a circuit breaker20-meter power cordProduct values:
  • Functionality - efficient pumping of water from the well to a maximum height of 96 m,
  • Efficiency - motor with a power of 2200 W providing a flow of 108000 l / h,
  • Simple operation - uncomplicated controller,
  • Convenient use - 20-meter power cord,
  • Durability - housing made of stainless steel.
Technical parameters:
  • - Model - MSW-SPP48-220
  • - Catalog no. - 10060174
  • - Article status - New
  • - Housing material - Stainless steel
  • - Rated power - 2200W
  • - Working power - 3000W
  • - Voltage - 230 V / 50 Hz
  • - Rated current - 14 A
  • - Max. lifting height of the water column - 96 m
  • - Max. flow rate - 10800 l/h
  • - Speed - 2850 rpm
  • - Protection class - I
  • - Ip protection class - IP68
  • - Insulation class - B
  • - Operating mode - S1
  • - Number of degrees - 14
  • - Mounting hole diameter - 95 mm
  • - Water connection size - 2
  • - Max. sand content in water - 0.25%
  • - Max. pumped water temperature - 35C
  • - Poppy. number of starts per hour - 50
  • - Dimensions (LxWxH) - 10 x 9 x 135.6 cm
  • - Weight - 25.15 kg
  • - Shipping dimensions (LxWxH) - 173 x 12 x 22.5 cm
  • - Shipping weight - 28 kg
Included:
  • - Submersible pump
  • - Manual EN
