| Certificates:: | CE |
|---|---|
| Dimensions:: | 82 x 29 x 24 mm |
| Input socket:: | RJ-45 |
| Input voltage:: | 44 - 57 V PoE |
| Maximum transmission range:: | 100 m (DATA) |
| Number of inputs:: | 1 x RJ-45 Socket - PoE |
| Number of outputs:: | 1 x RJ-451 plug x 2.1/5.5 mm plug on the cable |
| Output voltage:: | 12 VDC +/- 10% |
| Output:: | 0.8A / 12V DC (continuous operation) max. 1A / 12V DC (instantaneous operation) |
| Purpose of leds:: | PoE power supply - yellow |
| Scales:: | 0.05 kg |
| Standards:: | PoE (802.3af), PoE (802.3at) |
| Supported baud rate:: | Ethernet - 10 Mbps Half Duplex Fast Ethernet - 100 Mbps Full Duplex |
| Warranty:: | 2 years |
POE-802.3AF/C allows devices to be powered by DC 12V
Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum currentSpecial attention should be paid to the proper cooling of the power supply during operation!
At a load of 1.2 A, the protection of the power supply circuit is switched on. Lowering the current to 0.8 A restores normal operation
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
