Sound Card ELGATO 10MAG9901

€213.56
Shipping from warehouse: ⁨M7⁩
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
ELGATO
Product code:
10MAG9901 / 0840006642886

Specification

A/d dynamic range:100 dB
A/d frequency range:20 - 20000 Hz
Audio a/d converter (adc):24-bit/96kHz
Audio input:XLR
Audio output:3.5mm
Cables included:USB
Device interface:USB Type-C
Equipment:USB cable
Form factor:Desktop
Interface type:USB Type-C
Kind:External card
Led indicators:Yes
Line audio connectors:1x 3.5 mm jack (Microphone input), 1x 3.5 mm jack (Headphone out)
Mac operating systems supported:Yes
Maximum frequency response (khz):20
Minimum frequency response (hz):20
Other connectors:no
Other parameters:Dimensions: 8.8 x 11.8 x 8.4 cm
Power source:USB
Product colour:Black
Quick start guide:Yes
Sampling (bit):24
Sampling frequency (khz):96
Supported operating systems:Windows 10
Supported sample rates:48,96 kHz
Usb ports quantity:1
Usb version:3.2 Gen 1 (3.1 Gen 1)
Warranty:2 years
Weight:293 g
Windows operating systems supported:Windows 10
Xlr input:1

CONNECT YOUR MICROPHONE

You love your XLR microphone. You'll love it even more thanks to Wave XLR, a compact USB interface that gives your microphone superpowers

ALL IN ONE AND MORE

Wave XLR performs multi-device tasks and offers features not available in traditional audio interfaces, such as proprietary anti-distortion technology, a capacitive mute button, direct integration with Wave Link mixing software, and a replaceable faceplate.

HUGE POWER

Provide the necessary microphone gain without using an external preamplifier. Up to 75 dB of ultra-low noise amplification makes even low-sensitivity microphones sound loud and clear. In turn, 48 V phantom power allows the use of condenser microphones.

STRENGTHENING WITHOUT TRIMING

Now you don't have to keep an eye on levels during a live broadcast or try to save distorted audio in post-production. When the input reaches peak levels, proprietary Clipguard technology immediately routes sound through a second, lower-volume signal path. The result will be a clean audio output, no matter how loud you shout.

MASTERLY MIXING

Create two completely independent output mixes, one for yourself and one for your audience, and monitor each on the fly.

THOUSANDS OF EFFECTS

Add audio effects from the Marketplace or third-party VST plug-ins directly to your Wave Link mixer, without manual installation. Apply them to any input channel, such as microphone, game or voice chat, then adjust the settings to create your own sound.

YOUR WORKFLOW. IMPROVED.

Stream Deck works seamlessly with Wave Link software to give you complete control in the studio. Easily set keys to mute sources, adjust levels and skip tracks, the possibilities are endless. Or create multiple actions to adjust audio, lighting and camera settings simultaneously, all with one tap. This is advanced AV automation at your fingertips. Quickly responsive and adaptable. A hybrid, completely unique mixing solution.

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
