| Colour: | Brown |
|---|---|
| Detection: | Opening a door or window |
| Dimensions: | 51 x 9 x 12 mm |
| Distance of opening of reed contacts: | 33 mm |
| Maximum switchable current: | 500 mA |
| Maximum switchable voltage of reed switch: | 100 volts |
| Producer / brand: | SATEL |
| Reed switch closing distance: | 30 mm |
| Scales: | 0.02 kg |
| Selected features: | The sensor is designed for surface mounting |
| Warranty: | 2 years |
Magnetic detectors can be used wherever there is a need to control the condition of doors, windows or other moving elements, e.g. to protect or control access to specific objects, rooms, devices, automation systems, etc.
The sensor is designed for surface mounting
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
