Shuttle XPC slim Barebone DH32U5, Intel i5-1135G7, 4x HDMI 2.0b 2x LAN, 2x COM, incl. VESA 24/7 permanent operation
€880.72
Shipping from warehouse: A3
Estimated shipping: Mon, Nov 4 - Wed, Nov 6
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Shuttle
- Product code:
- 7600878 / 0887993004464
Share this product:
Specification
| Ac adapter included: | Yes |
|---|---|
| Ac adapter output current: | 4.74 A |
| Ac adapter output voltage: | 19 V |
| Ac input frequency: | 50 - 60 Hz |
| Ac input voltage: | 100 - 240 V |
| Audio output channels: | 5.1 channels |
| Bios type: | UEFI AMI |
| Built-in processor: | Yes |
| Built-in speaker(s): | No |
| Cable lock slot: | Yes |
| Cable lock slot type: | Kensington |
| Card reader integrated: | Yes |
| Chassis type: | 1.35L sized PC |
| Compatible memory cards: | SDXC, SD, SDHC |
| Cooling type: | Active |
| Country of origin: | China |
| Cpu configuration (max): | 1 |
| Dc-in jack: | Yes |
| Depth: | 165 mm |
| Drivers included: | Yes |
| Embedded options available: | No |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 2 |
| Graphics card family: | Intel |
| Harmonized system (hs) code: | 84713000 |
| Hdmi ports quantity: | 4 |
| Hdmi version: | 2.0b |
| Headphone outputs: | 1 |
| Height: | 43 mm |
| Housing material: | Metal |
| Idle states: | Yes |
| Intel stable image platform program (sipp): | No |
| Intel trusted execution technology: | No |
| Intel virtualization technology (vt-x): | Yes |
| Intel virtualization technology for directed i/o (vt-d): | Yes |
| Intel vt-x with extended page tables (ept): | Yes |
| Lan controller: | Intel® I211 |
| Led indicators: | Power, HDD |
| Linux operating systems supported: | Yes |
| Maximum internal memory: | 64 GB |
| Maximum resolution: | 4096 x 2304 pixels |
| Memory channels: | Dual-channel |
| Memory slots type: | SO-DIMM |
| Memory voltage: | 1.2 V |
| Microphone in: | Yes |
| Motherboard chipset: | Intel SoC |
| Number of m.2 (m) slots: | 1 |
| Number of memory slots: | 2 |
| Number of power supply units: | 1 |
| Number of processors supported: | 1 |
| Number of storage drives supported: | 2 |
| On-board graphics card: | Yes |
| On-board graphics card model: | Intel Iris Xe Graphics |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating system installed: | No |
| Operating temperature (t-t): | 0 - 50 °C |
| Package weight: | 2.1 kg |
| Pci express slots version: | 4.0 |
| Power cord included: | Yes |
| Power supply: | 90 W |
| Power supply type: | External AC adapter |
| Processor boost frequency: | 4.2 GHz |
| Processor cache: | 8 MB |
| Processor cores: | 4 |
| Processor family: | Intel® Core™ i5 |
| Processor generation: | 11th gen Intel® Core™ i5 |
| Processor lithography: | 10 nm |
| Processor manufacturer: | Intel |
| Processor model: | i5-1135G7 |
| Processor threads: | 8 |
| Product colour: | Black |
| Product type: | Mini PC barebone |
| Serial ports quantity: | 2 |
| Storage drive interface: | PCI Express, Serial ATA III |
| Storage drive sizes supported: | M.2, 2.5 |
| Supported memory clock speeds: | 3200 |
| Supported memory types: | DDR4-SDRAM |
| Supported storage drive types: | HDD & SSD |
| Trusted platform module (tpm) version: | 2.0 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 4 |
| Usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity: | 4 |
| Vesa mounting: | Yes |
| Weight: | 1.3 kg |
| Wi-fi: | No |
| Width: | 190 mm |
| Windows operating systems supported: | Windows 10, Windows 11 |
