Technical data:
- range - 150 mm
- outreach - 50 mm
- rail - 15 x 5 mm
- weight - 0,27 kg
- model - LMU15/5
Features:
- Clamping force up to 1 500 N
- Designed for bypassing protruding elements
- Fixed and movable arm protected by protective caps
- Small and handy
- Light weight
Fastening of hard-to-reach elements:
The fixed arm and rail are made as one element of high-quality drawn steel. The shape of the letter U allows you to attach in places,
access to which is hindered by protruding elements up to 20 mm long.
Movable arm:
The movable arm is made of die-cast zinc, making it lightweight, stable and resistant to cracks.
Protective caps:
Protective caps on the fixed and movable arm protect the elements exposed to damage.
