Magnetic detectors can be used wherever there is a need to control the condition of doors, windows or other moving elements, e.g. to protect or control access to specific objects, rooms, devices, automation systems, etc.
SATEL S-4-BR REED SWITCH
€11.23
Shipping from warehouse: H7
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Product code:
- S-4-BR / 5905033335189
Share this product:
Specification
| Colour:: | brown |
|---|---|
| Detection:: | Opening a door or window |
| Dimensions:: | Transmitter : 58.5 x 16.5 x 15.2 mm magnet : 58.5 x 14.7 x 8.3 mm |
| Manufacturer / brand:: | SATEL |
| Maximum switchable current:: | 20 mA |
| Maximum switchable voltage of the reed switch:: | 20 volts |
| Opening distance of reed switch contacts:: | 28 mm |
| Reed contact closing distance:: | 18 mm |
| Scales:: | 0.024 kg |
| Selected features:: | Cable Clamps Tamper Signaling |
| Warranty:: | 2 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
