| Alarm signaling:: | Suitable setting of 2 relay outputs, LED indicators displaying the operating status of the device |
|---|---|
| Detection:: | Temperature thresholds, Temperature gradient |
| Dimensions:: | 78 x 48 x 21 mm |
| Manufacturer / brand:: | SATEL |
| Operating temperature:: | -35 °C ... 60 °C |
| Permissible load on relay contacts (resistive):: | 1 A / 30 VDC |
| Power:: | 12 VDC / 50 mA |
| Probe cable length:: | 3 m |
| Scales:: | 0.04 kg |
| Temperature sensor:: | Built-in, external (probe) |
| Warranty:: | 2 years |
The detector allows you to program thresholds and gradient of temperature changes for which an alarm will be signaledThe device allows you to connect an external temperature probe
TD-1 has 2 relay outputs to control external devicesThe device is ideal for working in a server room, cold store, greenhouse, florist, children's room, etc.
