| Alarm signaling:: | Signal to the control panel |
|---|---|
| Battery life:: | Max. 3 years |
| Battery:: | CR123A 3 V |
| Colour:: | white |
| Cooperation:: | Satel MICRA, PERFECTA |
| Current consumption:: | 18 mA |
| Detection:: | Glass break sensor |
| Dimensions:: | 25 x 111 x 28 mm |
| Environmental class en 50130-5:: | II |
| Frequency band:: | 433.05 MHz ... 434.79 MHz |
| Manufacturer / brand:: | SATEL |
| Operating temperature:: | -10 °C ... 55 °C |
| Permissible relative humidity:: | 93 ± 3 % |
| Radio communication range (in open area):: | Max. 200 m |
| Scales:: | 0.04 kg |
| Selected features:: | Plain Glass Breaking, Laminated Tempered Test Mode Smooth Sensitivity Adjustment |
| Warranty:: | 2 years |
The sensor signals an alarm if it registers a low-frequency signal (impact sound) and a high-frequency signal (broken glass sound)A low-frequency sound wave caused by an impact causes the sensor to start analyzing the high-frequency channel
High-frequency channel analysis takes 4 secondsIf a high-frequency sound occurs during this time, i.e. the sound of broken glass, the sensor triggers an alarm
