SATEL AXD-200-DG ABAX/ABAX2 WIRELESS UNIVERSAL DETECTOR

Name: SATEL AXD-200-DG ABAX/ABAX2 WIRELESS UNIVERSAL DETECTOR
Brand: Satel
SKU: 515452
Price: 52.99 EUR
Availability: InStock

€52.99

Shipping from warehouse: ⁨H7⁩

Estimated shipping: Mon, Oct 21 - Tue, Oct 22

14 days returnUnconditional return policy

Availability:: large quantity
Brand:
Product code:: AXD-200-DG / 5905033336599

Specification

Accuracy:	1%
Alarm signaling::	Signal to the control panel
Battery life::	~ 2 years
Battery type:	CR123A
Battery voltage:	3 V
Battery::	CR123A 3 V - 3.0 V (included)
Colour::	Dark graphite
Connectivity technology:	Wireless
Cooperation::	ABAX/ABAX2
Depth:	102 mm
Dimensions::	20 x 102 x 23 mm
Frequency band::	868 MHz ... 868.6 MHz
Height:	23 mm
Manufacturer / brand::	SATEL
Number of batteries supported:	1
Operating relative humidity (h-h):	0 - 93%
Operating temperature (t-t):	-10 - 55 °C
Operating temperature::	-10 °C ... 55 °C
Purpose:	Indoor
Radio communication range (in open area)::	~ 500 m @ ABAX, ~ 2000 m @ ABAX2
Scales::	0.023 kg
Selected features::	Operating modes : Magnetic detector Two-channel magnetic detector Magnetic detector with roller shutter input - Input for additional wired detector Shock and magnetic detector - Detection of shocks and vibrations accompanying attempts to force through a door or window Displacement detector - Detection of change in the position of the object Temperature sensor - Temperature measurement in the range of -10°C ... +55°C, Two programmable temperature thresholds (upper and lower) Water flood sensor - FPX-1 probe required separately available Tamper detection - enclosure opening, detachment from the ground Remote configuration Remote module software update LED to indicate violations in test mode, facilitating commissioning and subsequent maintenance of the system
Sensor type:	Temperature sensor
Temperature measuring range:	-10 - 55 °C
Type:	Freestanding
Warranty::	2 years
Weight:	59 g
Width:	20 mm

The AXD-200-DG wireless detector can work in one of 7 modes, which makes it an extremely versatile deviceThe device, depending on your needs, can be configured as: two-channel magnetic detector, magnetic detector with roller shutter input (for wired sensor), shock detector with reed switch, object position change sensor, temperature detector, or water flood detector (external FPX-1 probe required - available separately)

AXD-200-DG works with other devices compatible with the ABAX/ABAX2 wireless system

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
