MECHANICAL PARAMETERS:
Yield strength Re [N/mm2]: >420
Strength Rm [N/mm2]: 500-640
Elongation A5 [%]: >20
Impact strength Kv [J]: >47J (0°C)
Electrode type (sheath): rutile-cellulose
Drying: 140°C / 1h
USABLE FEATURES:
Especially recommended for welding galvanized sheets: zinc curls up before the weld, so that less impurities enter the air, increasing the safety of the welder.
Coarse-othutulone rutile-cellulose electrode.
For assembly and repair work (e.g. in shipbuilding and construction).
Very good welding properties in all positions, including forced positions.
Good weldability when welding contaminated material (rust, paint, grease).
Very good blending.
It forms a flat weld with a smooth face.
USE:
Steel structures: trusses, portal frames, tubular frames.
Structures made of sheet metal and container sheathing, storage tanks, hoppers, silos.
Connecting pipes in the field for the transmission of various utilities.
Light steel frames - grills, furniture, gates, ornaments.
Welding of agricultural equipment.
General workshop welding and maintenance.
Welding of all types of mild (low carbon) steel.
