Specifications
Laser diode 635 nm, < 5 mW
Operating temperature -10 – 50 °C
Storage temperature -20 – 70 °C
Laser class 3R
Working range 60 m
Working range with receiver 300 m (Diameter)
Operating range without receiver, value 60 m (Diameter)
Leveling accuracy ± 0.1 mm/m
Automatic leveling range ± 5° (8%)
Leveling time 15 s
Dust and water protection IP 54
Rotational speed 150, 300, 600 rpm
Power supply 2 batteries 1.2 V HR20 (D) (9 Ah)
2 x 1.5V LR20 batteries (D)
Max. battery life (NiMH) 30 h
Tripod thread 5/8"
Weight, approx. 1.8 kg
Length 190 mm
Width 180 mm
Height 170 mm
Laser beam color red
