Mounting kit roof rafter bracket 30cm, mast Fi 38
Fastening the mast to the rafters of the roof consisting of two parts, which we attach to the wooden rafters of the roof. Handle construction made of hot-dip galvanized steel. Possibility to mount a mast with a diameter of 38 mm.
- distance from rafters: 300mm
- possibility of mounting the mast: 380mm
- tube: fi 38mm
- mounting plate "L":
sheet metal with welded mast – 120x120mm, spacing of mounting holes 85x75 mm
sheet - 75x75mm, spacing of mounting holes 85mm + tear 45x10mm
- included with mast mounts
- steel mast, galvanized, with a cap
