AC type residual current circuit breaker with rated residual current IΔn = 30mAThe LE-411707 switch is designed for mounting on the TS-35 DIN rail
RESIDUAL CURRENT CIRCUIT BREAKER LE-411707 THREE-PHASE, TYPE AC 30 mA 25 A LEGRAND
€58.25
Shipping from warehouse: D4
Estimated shipping: Tue, Dec 24 - Fri, Dec 27
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Legrand
- Product code:
- LE-411707 / 3414970353061
Share this product:
Specification
| Case:: | Plastic, DIN rail mounting, TS-35 |
|---|---|
| Connector type:: | screw terminals |
| Current:: | 25 A |
| Device type:: | Residual current circuit breaker, Three phase, Type AC |
| Dimensions:: | 71 x 83 x 75 mm |
| Manufacturer / brand:: | LEGRAND |
| Number of poles:: | 4 |
| Rated differential current:: | 30 mA |
| Rated short-circuit switching capacity:: | 10000 A |
| Scales:: | 0.316 kg |
| Selected features:: | Can be equipped with auxiliary contacts, triggers and drives from the DX3 series Provided space for a sheet of paper with a description Can be connected using comb or stick rails |
| Voltage:: | 400 V AC / 50 Hz |
| Warranty:: | 2 years |
| Width in modules 17.5 mm:: | 4 |
