It allows to increase the current carrying capacity of transistor outputs and introduces galvanic isolation between the trigger signal and the load
RELAY MODULE PK4-12-ZW
€19.05
Shipping from warehouse: D4
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Delta
- Product code:
- PK4-12-ZW / 5902887037955
Share this product:
Specification
| -25 °c ... 70 °c: | Operating temperature: |
|---|---|
| 0.12 kg: | Scales: |
| 10 ... 16 vdc: | Power: |
| 10 a (max), 30 v dc / 50 v ac (max): | Contact capacity: |
| 118 x 91 x 37 mm: | Dimensions: |
| 3 years: | Warranty: |
| 35 ma per relay at 12 v dc: | Current consumption: |
| 4: | Number of relay outputs: |
| 4 x no: | Egress: |
| Delta: | Manufacturer / Brand: |
| Led signalling, protection : surge protector, reverse connection splash-proof housing: | Selected features: |
| Relay for controlling electric strike, bolt or electromagnetic interlock: | Use: |
