Reamer of machines. DIN212TiN,pcs. D,10.0mm BECK

€74.70
Shipping from warehouse: ⁨B6⁩
Estimated shipping: Tue, Nov 26 - Fri, Nov 29
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
BECK
Product code:
30107964 / 4332163927242

Specification

Cast iron gg/gts:12
Copper alloys:20
Cutting part length:38.0 mm
Ggg cast iron:10
Grip ø h8:10.0 mm
Ø nominal d1:10.0 mm
Overall length:133 mm
Steel < 1000 n/mm2:10
Steel < 1400 n/mm2:10
Steel < 700 n/mm2:12

Machine reamer

Execution: HSS-E, with a left-handed spiral of approx. 7°, a short cut and an uneven interblade pitch. Thanks to this, a clean and precise hole is made. With cylindrical grip. Tolerance h9.
Application: for reaming through holes, thanks to the short cut it can also be used for blind holes. Used for steel, structural steels, free-cutting steels, heat conditioning steels, carburizing, tooling, high-speed steel, cast steel, ductile iron and malleable cast iron, soft non-ferrous metals such as aluminum and brass.

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
