The driving force behind the computer are its components – motherboard, graphics card, processor and other components. To ensure proper and trouble-free operation of all components, you need to ensure that they are reliably powered. The more demanding the components, the more efficient the power supply you need. The Qoltec brand has prepared for you a wide selection of products, among which you will find the right model for yourself.
The ATX motherboard standard is the most popular choice for users around the world. Its popularity is due to clearly defined rules regarding the dimensions and convenient arrangement of ports. The task of the ATX power supply is to provide a stable voltage to the computer. In addition, our product offers:
- passive cooling system extremely quiet during operation,
- protection system: undervoltage, overvoltage, overcurrent, short-circuit, thermal,
- 100,000 hours of trouble-free operation is a guarantee of the highest quality.
Power supplies with passive cooling system are extremely quiet, which is due to the lack of a fan. The principle of its work is very simple – it absorbs heat flowing from the inside of the computer and through metal gives it to the environment. The disadvantage of this type of cooling is lower efficiency compared to active or semi-passive cooling.
Do you care about the high quality of the product you buy? Our solutions will meet your expectations. Each of the power supplies we offer is covered by a 24-month warranty valid from the date of purchase.
Qoltec
505 watts (Printing)
Fan 120 x 120 x 25 mm
19 - 23 dB with automatic speed control
Passive (PPFC)
MOLEX - 4 pcs SATA - 2 pcsFDD - 1 pcsPCIExpress - 1 pc
ATX 20 + 4 pin (black braid) - 1 pcsATX 12 V (black braid) - 2 pcs
100000 hours
Short circuit suppression (SCP) Against too high current (OCP) Against too high voltage (OVP) Against too low voltage (UVP)Thermal (OTP)
ATX power supplies designed only for telecommunications equipment and for automatic data processing equipment.
Grey
85
200
150
150 x 140 x 86 mm
1.1600 kg
1.1700 kg
Due to the technological process, cable lengths may vary +/- 5-10%
24 months
Qoltec Power Supply ATX Wind 505W (0NC)
€45.02
Shipping from warehouse: N6
Estimated shipping: Mon, Nov 25 - Wed, Nov 27
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Qoltec
- Product code:
- ATX 505W WIND / 5908260270438
Share this product:
Specification
| Ac input frequency: | 50 Hz |
|---|---|
| Ac input voltage: | 230 V |
| Cabling type: | Non-Modular |
| Cooling type: | Active |
| Depth: | 86 mm |
| Fan diameter: | 12 cm |
| Floppy disk drive connector: | Yes |
| Height: | 140 mm |
| Input current: | 5 A |
| Max output current (-12v): | 0.5 A |
| Max output current (+12v): | 19 A |
| Max output current (+3.3v): | 32 A |
| Max output current (+5v): | 32 A |
| Max output current (+5vsb): | 2 A |
| Mean time between failures (mtbf): | 100000 h |
| Motherboard power connector: | 20+4 pin ATX |
| Noise level: | 22 dB |
| Number of sata power connectors: | 2 |
| Pci express connector: | Yes |
| Peripheral (molex) power connectors (4-pin): | 4 |
| Power factor correction (pfc) type: | Passive |
| Power protection features: | Short circuit, Over voltage, Under voltage, Over current |
| Power supply unit (psu) form factor: | ATX |
| Product colour: | Grey |
| Purpose: | PC |
| Total power: | 505 W |
| Width: | 150 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
