| Battery charging current: | 4 A |
|---|---|
| Battery space: | 12V/33Ah, 12V/40Ah |
| Current efficiency (total): | 10 amps |
| Dimensions: | 330 x 350 x 175 mm |
| Input voltage: | 85 ... 264 VAC |
| Max. battery dimensions: | 370 x 230 x 170 mm |
| Output voltage: | 13.8 V DC (mains mode) 10.5 ... 13.8 V DC (battery mode) |
| Power: | 151 watts (Printing) |
| Power supply operation control: | Indication of the presence of mains power Indication of the presence of output voltage |
| Scales: | 3.9 kg |
| Security: | Short-circuit overload overvoltage against over-discharge |
| Type of power supply: | Pulse |
| Warranty: | 2 years |
The buffer power supply is designed to power alarm control panels, sensors, code locks, cameras, keypads, intercoms and other devices included in the alarm system
Remark! If the power supply is designed for continuous operation (24H), the rated current of the power supply should not exceed 80% of the maximum current
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
