POWER SUPPLY FOR SWITCHING MODE DL2-60-48-U

€23.01
Shipping from warehouse: ⁨D4⁩
Estimated shipping: Mon, Nov 25 - Tue, Nov 26
14 days returnUnconditional return policy
Availability:
running out
Product code:
DL2-60-48-U / 5902135153451

Specification

Dimensions:92.7 x 52 x 58 mm
Efficiency:91 %
Enclosure type:DIN
Number of outputs:2 pcs.
Operating temperature / relative humidity:-40 °C ... 70 °C / 10 ... 95 %
Output voltage:48 VDC
Output voltage adjustment:43.2  ... 55.2 volts DC
Power supply:60 watts (Printing)
Power supply current efficiency:1.25 amps
Scales:0.18 kg
Security:Short circuit overload suppression surge protector
Supply voltage:85  ... 264 volts AC 120 ... 370 VDC
Type of power supply:Pulse
Warranty:3 years

Switch mode power supply installed on TS35/7.5 or 15 DIN rail, resistant to high operating temperatures (up to 70°C)

Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
