| Baud: | 10 / 100 / 1000 Mbps : 2 x Uplink Port, 10 / 100 Mbps : 16 x LAN & PoE Port |
|---|---|
| Dimensions: | 440 x 220 x 180 mm - 19" RACK, 5U |
| External dimensions of the enclosure: | 484 x 225 x 202 mm |
| Lan ports: | 2 x RJ45 10/100/1000 Base-T - Uplink, 16 x RJ45 10/100 Base-T + PoE (802.3af/at) / Passive PoE |
| Leds: | AC, DC, CHARGING, PoE, Gigabit Ethernet |
| Maximum output power: | 40 W @ Passive PoE - LAN1 Ports... LAN8, 30 W @ PoE (802.3af/at) - LAN1 ports ... LAN8 |
| Maximum total power: | 130 watts (Printing) |
| Operating modes: | Standard : 100 m @ 10/100 Mbps - LAN1 ports ... LAN8 |
| Power: | 190 ... 260 VAC |
| Producer / brand: | ATTE |
| Scales: | 3.42 kg |
| Selected features: | 4K UHD Support Ability to independently turn PoE power on and off for each of the LAN ports 1 ... LAN 16 Modular design streamlines service tasks and enables quick, easy system expansion Raster module mounting system makes it easy to expand the device with more modules 2 x Space for battery : 12 V / 18 Ah Battery charging current : 1 A / 2 A - (set by jumper JP1) Battery - Protection against reverse polarity connection, Deep discharge protection of the battery OC type technical outputs signaling power loss at the output of the power supply (OUF) and voltage loss in the 230V network (ACF) Thermal protection of the power supply: 130 °C Overload protection LAN & PoE ports - Short circuit protection, Surge protector Can be installed in a 19" rack Degree of protection: IP20 |
| Warranty: | 3 years |
16-Port PoE switch in RACK enclosure with buffer power supply16 ports supports Power over Ethernet (PoE)
The IPUPS-16-20-R5U0 set consists of 2 XPOE-10-20A-OF switch modules, 2 AUPS-70-120-OF buffer power supply modules and 2 ASUC-100-480-OF voltage converter modules enclosed in an ABOX-R5U0 RACK cabinet housing with space for 2 x 18Ah batteriesBuffer power supplies are designed to work with maintenance-free batteries (gel or AGM) with a nominal voltage of 12V
