| Baud:: | 10 / 100 Mbps |
|---|---|
| Dimensions:: | 94 x 41 x 18 mm |
| Lan ports:: | 1 x LAN + PoE IN - LAN port 1, 3 x LAN + PoE OUT - LAN2 ports ... LAN4 |
| Leds:: | Power, LAN |
| Manufacturer / brand:: | ATTE |
| Maximum output power:: | 40W @ Passive PoE - LAN2 Ports ... LAN4 13 W / 25 W @ PoE (802.3af/at) - LAN2 ports ... LAN4 |
| Power:: | 44 ... 56 V DC - LAN 1, 12 ... 56 V DC - LAN 2 ... LAN 4 |
| Scales:: | 0.04 kg |
| Selected features:: | Can power up to 3 802.3at/af or PASSIVE PoE receivers Cascading capability Ability to turn off power on selected PoE ports The PoE output voltage is equal to the input voltage Surge protection Short-circuit protection - LAN 1 |
| Warranty:: | 3 years |
XPOE-4-11A-HS is designed as an extender (repeater) of LAN and PoE power supplyThe device regenerates the network signal and transfers PoE power to selected outputsIt is most often used as an "amplifier" to extend the network over distances longer than 100m
In addition, it works perfectly as an "active splitter" in situations where we want to run several PoE receivers (e.g. several IP cameras) on one cable, or when we need to create an additional network branch
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
