| Baud:: | 10 / 100 / 1000 Mbps : 2 x LAN, 10 / 100 Mbps : 8 x LAN & PoE ports |
|---|---|
| Certificates:: | CE |
| Dimensions:: | 220 x 143 x 41 mm |
| Lan ports:: | 10 x RJ45 ( 8 x PoE (802.3af/at) ) |
| Leds:: | LAN, PoE |
| Mac address table:: | 2k |
| Manufacturer / brand:: | APTI |
| Maximum output power:: | 30 W/ PoE port |
| Maximum total power:: | 120 watts (Printing) |
| Operating temperature:: | 0 °C ... 55 °C |
| Power:: | 230 VAC |
| Scales:: | 0.74 kg |
| Selected features:: | 2 x Uplink Port PoE Range: 200m - EXTEND Mode On |
| Warranty:: | 2 years |
With reliability and high transmission quality, the APTI-POE0802G-120W 8-port PoE switch is the ideal solution for IP CCTV applications
Remark! Enabling the Extend function increases the PoE range to 200m and reduces the transmission speed to 10 Mbps
