Płyta główna Gigabyte H610M K DDR4
€91.78
Shipping from warehouse: A3
Estimated shipping: Mon, Apr 7 - Thu, Apr 10
14 days returnUnconditional return policy
- Availability:
- large quantity
- Brand:
- Gigabyte
- Product code:
- H610M K DDR4 / 4719331851675
Share this product:
Specification
| 12v power connector: | Yes |
|---|---|
| Atx power connector (24-pin): | Yes |
| Audio connector: | Yes |
| Audio output channels: | 7.1 channels |
| Bios type: | UEFI AMI |
| Clear cmos button: | Yes |
| Clear cmos jumper: | Yes |
| Compatible processor series: | Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Celeron®, Intel® Core™ i3 |
| Cooling type: | Active |
| Cpu fan connector: | Yes |
| Depth: | 185 mm |
| Desktop management interface (dmi) version: | 2.7 |
| Ethernet interface type: | Gigabit Ethernet |
| Ethernet lan: | Yes |
| Ethernet lan (rj-45) ports: | 1 |
| Front panel audio connector: | Yes |
| Front panel connector: | Yes |
| Graphics card: | HD Graphics |
| Graphics card family: | Intel |
| Hdcp: | Yes |
| Hdmi ports quantity: | 1 |
| Headphone outputs: | 1 |
| Line-in: | Yes |
| Maximum internal memory: | 64 GB |
| Maximum resolution: | 4096 x 2160 pixels |
| Memory channels: | Dual-channel |
| Memory slots type: | DIMM |
| Microphone in: | No |
| Motherboard chipset: | Intel H610 Express |
| Motherboard chipset family: | Intel |
| Motherboard form factor: | micro ATX |
| Number of memory slots: | 2 |
| Number of sata iii connectors: | 2 |
| Number of storage drives supported: | 1 |
| On-board graphics card: | Yes |
| Pc health monitoring: | Temperature, Voltage, Water cooling, Fan |
| Pci slots: | 1 |
| Power fan connector: | Yes |
| Power source type: | ATX |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1700 |
| Supported memory clock speed (max): | 3200 MHz |
| Supported memory clock speeds: | 2933, 2133, 3200 MHz, 3000, 2666, 2400 |
| Supported memory module capacities: | 32GB |
| Supported memory types: | DDR4-SDRAM |
| Supported storage drive interfaces: | M.2, PCI Express 3.0, SATA |
| Tpm connector: | Yes |
| Usb 2.0 connectors: | 1 |
| Usb 2.0 ports quantity: | 4 |
| Usb 3.2 gen 1 (3.1 gen 1) connectors: | 1 |
| Usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: | 2 |
| Wi-fi: | No |
| Width: | 226 mm |
| Windows operating systems supported: | Windows 11 x64, Windows 10 x64 |
