PERFECTA-T-32-WRL SATEL CONTROL PANEL BOARD

€135.88
Shipping from warehouse: ⁨H7⁩
Estimated shipping: Mon, Dec 30 - Tue, Dec 31
14 days returnUnconditional return policy
Availability:
moderate quantity
Brand:
Satel
Product code:
PERFECTA-T-32-WRL / 5905033333468

Specification

Dimensions:160 x 110 mm
Event memory:3584
Grade:2
Maximum number of supported inputs:32 pcs. -Programmable
Maximum number of supported outputs:12 pcs. -Programmable
Motherboard inputs:8 pcs. -Programmable
Motherboard outputs:4 pcs. -Programmable
Operating temperature:-10 °C ... 55 °C
Permissible relative ambient humidity:93 %
Power:18 V AC
Power supply current efficiency:2 A
Producer / brand:SATEL
Scales:0.104 kg
Selected features:Built-in dialer Built-in voice module (playback of voice messages for telephone notification) - 16 voice messages Built-in acoustic alarm verification module (listening to sounds) Two-way communication with PRF-LCD-WRL wireless keypads and MSP-300-R sirens takes place in the 433 MHz band Wireless one-way communication with MICRA series detectors and MPT-350 keyfobs in the 433 MHz band 3 surveillance modes in each zone Possibility to assign input to two zones User or timer control Communication bus for connecting keypads (PRF-LCD) and expansion modules (INT-E, INT-O, INT-ORS) Edit names (users, zones, inputs, outputs and modules) for easy system control and supervision Built-in advanced power supply with extensive diagnostics - 2 power outputs Support for vibration and roller shutter detectors Software upgradeable self-diagnostic function
Supported keyboards:.max. 4 pcs.
Supported languages:Polish - no possibility to change the language
Timers:8
Users + administrators:15  + 1
Warranty:2 years
Zone:2

PERFECTA-T series control panels are designed to protect small and medium-sized buildings, such as apartments, single-family houses, segments in terraced houses, offices, small businesses, etc. Provides protection in accordance with EN 50131 Grade 2 requirements

The PERFECTA-T-32-WRL control panel enables the creation of wireless and hybrid installations (connection with a traditional wired system)Two-way communication with wireless keypads PRF-LCD-WRL and MSP-300-R sirens takes place in the 433 MHz bandThe wireless system also uses MICRA series detectors and new MPT-350 keyfobsThis makes it possible to easily expand the existing system, without the need to lay additional cable paths

The built-in PSTN telephone dialer can be used to monitor events (e.g. to a security agency monitoring station) and voice notification, as well as audio verification (listening to sounds from a protected facility)
