| 10g support: | N |
|---|---|
| Ac input frequency: | 50/60 Hz |
| Ac input voltage: | 110 - 240 V |
| Auto mdi/mdi-x: | Y |
| Auto-negotiation: | Y |
| Auto-sensing: | Y |
| Basic switching rj-45 ethernet ports quantity: | 48 |
| Basic switching rj-45 ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Built-in memory: | Buffer 1.5 MB |
| Bus speed: | 96 Gbps |
| Cable length detection: | Y |
| Cables included: | AC |
| Colour: | Black |
| Configuration and management: | no |
| Copper ethernet cabling technology: | 100BASE-TX, 10BASE-T, 1000BASE-T |
| Depth: | 310 mm |
| Depth (mm): | 310 |
| Destiny: | Rack |
| Forwarding rate: | 1.448 Mpps |
| Full duplex: | Y |
| Heat dissipation: | 1402.2 BTU/h |
| Height: | 43 mm |
| Height (mm): | 42 |
| Housing material: | Metal |
| Jumbo frame support: | yes |
| Jumbo frames: | 12288 |
| Jumbo frames support: | Y |
| Latency (1 gbps): | 4 µs |
| Led indicators: | Link, Power, PoE, Activity, Speed |
| Mac address array size: | 8000 |
| Mac address table: | 8000 entries |
| Mean time between failures (mtbf): | 570972 h |
| Network ports: | 24x 10/100/1000, 24x 10/100/1000 PoE+ |
| Networking standards: | IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3i, IEEE 802.3at, IEEE 802.3u |
| Number of fans: | 2 fan(s) |
| Operating altitude: | 0 - 3000 m |
| Operating relative humidity (h-h): | 10 - 90% |
| Operating temperature (t-t): | 0 - 45 °C |
| Packet buffer memory: | 1.5 MB |
| Packet forwarding rate (1 gbps): | 1448000 pps |
| Power: | Network |
| Power consumption (max): | 410 W |
| Power over ethernet (poe): | Y |
| Power over ethernet (poe) ports quantity: | 24 |
| Power over ethernet (poe) power per port: | 30 W |
| Product colour: | Black |
| Protocols and standards: | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Quality of service (qos) support: | Y |
| Queue scheduling algorithms: | Weighted Round Robin (WRR) |
| Rack mount kit: | Y |
| Rack mounting: | Y |
| Storage relative humidity (h-h): | 10 - 95% |
| Storage temperature (t-t): | -20 - 70 °C |
| Switch type: | Unmanaged |
| Switching capacity: | 96 Gbit/s |
| Technologies: | RJ-45 |
| Total power over ethernet (poe) budget: | 380 W |
| User guide: | Y |
| Warranty: | 3 years |
| Weight: | 4.56 kg |
| Weight (g): | 4560 |
| Width: | 440 mm |
| Width (mm): | 440 |
PLUG-AND-PLAY:
Simple set up with no software to install or configuration needed
FULL PERFORMANCE:
Non-blocking switching architecture for maximum throughput at wire speed
CONNECT DEVICES:
power IP Security Cameras, VoIP phones, wireless access points, and other PoE PD-powered devices
PoE POWER AUTO-BALANCE AND ALLOCATION:
NETGEAR's unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs.
