MULTI-BAND AMPLIFIER MA-049L
€72.74
Shipping from warehouse: D4
Estimated shipping: Thu, Nov 14 - Mon, Nov 18
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Product code:
- MA-049L / 5902887050107
Share this product:
Specification
| Amplification:: | 30 dB@FM30 dB@VHF34 dB@UHF |
|---|---|
| Dimensions:: | 179 x 135 x 52 mm |
| Frequency range:: | 88 MHz ... 108 MHz - FM, 174 MHz ... 230 MHz - VHF, 470 MHz ... 790 MHz - UHF |
| Gain adjustment:: | 0 dB ... 20 dB |
| Maximum output level imd3=60 db din45004b:: | 112 dBμV |
| Noise ratio:: | < 6 dB @ VHF< 5 dB @ UHF |
| Number of inputs/outputs:: | 3 / 1 + 1 (test, -30dB) |
| Operating temperature:: | -20 °C ... 50 °C |
| Power consumption:: | 7 watts |
| Power:: | 230 VAC |
| Scales:: | 0.67 kg |
| Warranty:: | 2 years |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
