| Aluminium > 8% silicon: | 25 |
|---|---|
| Execution: | with through grip |
| Inox austenite.: | 8 |
| Inox ferrite./martenz.: | 10 |
| Jump: | 1.75 mm |
| Overall length: | 110 mm |
| Shank diameter: | 9.0 mm |
| Square grip: | 7.0 mm |
| Standard: | DIN 376 |
| Thread: | M12 |
| Thread hole diameter: | 10.20 mm |
Machine tap for through holes
Design: ISO 2/6H tolerance field, INOX type, B shape (4–5 turns).
Application: for metric threads according to ISO DIN 13. Designed especially for stainless and acid-resistant steels such as sulfurized, austenitic, martensitic and ferritic steels.
Remark: HSS-E PM is characterized by high ductility (greater edge stability and resistance to abrasive wear) and longer durability.
