| Aluminium > 8% silicon: | 25 |
|---|---|
| Execution: | with through grip |
| Jump: | 1.75 mm |
| Overall length: | 110 mm |
| Shank diameter: | 9 |
| Square grip: | 7 |
| Standard: | DIN 376 |
| Steel < 1000 n/mm2: | 8 |
| Steel < 700 n/mm2: | 12 |
| Thread: | M12 |
| Thread hole diameter: | 10.2 mm |
Machine tap for through holes
Execution: HSS-E, tolerance area ISO 2/6H, type N, section shape B (4-5 turns).
Application: for metric threads according to ISO DIN 13. Designed in particular for ordinary, structural, free-cutting steels, carburizing steels and heat conditioning steels.
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
