| Aluminium > 8% silicon: | 25 |
|---|---|
| Execution: | with through grip |
| Ggg cast iron: | 25 |
| Inox austenite.: | 8 |
| Inox ferrite./martenz.: | 10 |
| Jump: | 2.00 mm |
| Overall length: | 110 mm |
| Shank diameter: | 11.0 mm |
| Square grip: | 9.0 mm |
| Standard: | DIN 376 |
| Steel < 1000 n/mm2: | 15 |
| Steel < 1400 n/mm2: | 10 |
| Steel < 700 n/mm2: | 20 |
| Thread: | M14 |
| Thread hole diameter: | 12.00 mm |
Machine tap for through holes
Execution: M3–M10 DIN 371 with reinforced grip.
M12–M30 DIN 376 with through grip.
Application: for metric threads according to ISO DIN 13. Designed especially for universal materials such as structural steels, automatic steels, carburizing steels and heat treatment.
