| Aluminium > 8% silicon: | 25 |
|---|---|
| Execution: | with reinforced grip |
| Inox austenite.: | 15 |
| Inox ferrite./martenz.: | 25 |
| Jump: | 0.80 mm |
| Overall length: | 70 mm |
| Shank diameter: | 6.0 mm |
| Square grip: | 4.9 mm |
| Standard: | DIN 371 |
| Thread: | M5 |
| Thread hole diameter: | 4.20 mm |
Machine tap for blind holes
Execution: HSS-E, tolerance field ISO 2 6H, type INOX, shape of section C (2-3 turns).
Application: for metric threads according to ISO DIN 13. Designed especially for stainless and acid-resistant steels such as sulfurized, austenitic, martensitic and ferritic steels.
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
