LASER RANGEFINDER DL-80X

TECHNICAL DATA:
Measuring range: 0.05 m - 80 m
Resolution: 0.001 m
Measurement accuracy: +/- 2 mm
Measuring Time: 0.5s (6Hz)
Units of measurement: meters, inches, feet/inches, feet
Laser Type: 635nm, Class 2, <1mW
Power Supply: 3x 1.5V AAA battery
Battery life: about 8000 measurements
Dimensions: 118 mm x 52 mm x 27 mm
Operating temperature: 0°C to 40°C
Storage temperature: -20°C to 60°C
Automatic shutdown:
Laser: 20 s each
Rangefinder: after 150 s
Number of memorized measurements: 99
Humidity: 20% - 80%
Auto Backlight: Yes
Button Sound: Yes
Libella: electronic
Time delay: Yes (3 - 60 s)
Enclosure protection class: IP54
Tripod mount: Yes (1/4" thread)
Measurement reference setting: Yes (front panel, back panel and 1/4") socket

FUNCTIONAL FEATURES:
The DL-80X laser rangefinder is used to measure the distance of the surface and the volume of the selected product
It has the following functions: indirect measurement (enriched with the ability to calculate the sum and difference), continuous and dynamic measurement
Allows work in the range from 0.05m to 80m
Measurement accuracy is +/- 2 mm
Units of measurement to choose from: meters, inches, feet/inches, feet
Three measuring reference points: front wall, rear wall and 1/4" socket
Built-in digital protractor (in °)
Backlit LCD screen
Extensive memory allows you to save measurements (up to 99) and perform addition and subtraction actions on them
Protection class IP54
Non-slip buttons
Tripod mount 1/4"

STANDARD EQUIPMENT:
Laser rangefinder DL-80X (3-01-06-L1-077)
Case
Strap
Gray card (for contrast)
