IP Recorder DAHUA NVR4108HS-P-4KS2/L
€126.31
Shipping from warehouse: D4
Estimated shipping: Mon, Nov 11 - Wed, Nov 13
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Dahua
- Product code:
- NVR4108HS-P-4KS2/L / 6939554981524
Share this product:
Specification
| Archiving on external media: | Archiving to a USB drive (pendrive, external drive) |
|---|---|
| Audio inputs: | 1 pc CINCH |
| Audio outputs: | 1 pc CINCH |
| Audio rca outputs: | 1 |
| Audio support: | 8 Channels - Audio from cameras |
| Backup function: | Yes |
| Bitrate: | .max. 80 Mbps |
| Built-in display: | No |
| Built-in optical drive: | No |
| Built-in processor: | Yes |
| Card reader integrated: | No |
| Default administrator login / password: | admin / -Administrator password must be set on first run |
| Default ip address: | 192.168.1.108 |
| Depth: | 232.5 mm |
| Dimensions: | 260 x 233 x 50 mm |
| Ethernet lan (rj-45) ports: | 1 |
| Ethernet lan data rates: | 10, 100 |
| Hdd interface: | SATA III |
| Hdmi output: | Yes |
| Hdmi ports quantity: | 1 |
| Height: | 50.3 mm |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Led indicators: | Yes |
| Maximum frame rate: | 30 fps |
| Maximum resolution: | 3840 x 2160 pixels |
| Maximum storage capacity: | 10 TB |
| Mobile app access port: | 37777 |
| Mobile operating systems supported: | iOS, Android |
| Mobile phone access: | Port: 37777 or cloud access (P2P) Android: Free DMSS app iOS (iPhone): Free DMSS app Watch the video on how to configure P2P in Dahua DVRs and how to enable the mobile application |
| Multi-screen: | Yes |
| Network features: | Full network support, Remote copying of recordings, Built-in web server |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, Alarm Server, IP Search, P2P, Auto Register, ONVIF |
| Number of hdds supported: | 1 |
| Number of simultaneously playbacked channels: | 8 channels |
| Operating system installed: | Linux |
| Operating temperature (t-t): | -10 - 55 °C |
| Output current: | 1.25 A |
| Output voltage: | 48/53 V |
| Package depth: | 373 mm |
| Package height: | 307 mm |
| Package weight: | 1.86 kg |
| Package width: | 117 mm |
| Pc app access ports: | 37777 |
| Playback modes: | Pause, Fast forward, Play, Fast reverse, Digital zoom, Full screen, Backup selection, Previous camera, Frame by frame, Shutter |
| Power: | 48 V DC / 1.25 A (adapter included) |
| Power consumption (max): | 36 W |
| Power over ethernet (poe): | Yes |
| Power over ethernet (poe) ports quantity: | 4 |
| Power over ethernet (poe) power per port: | 25.5 W |
| Processor cores: | 2 |
| Producer / brand: | DAHUA |
| Product colour: | Black |
| Rack capacity: | 1U |
| Rack mounting: | Yes |
| Rca input: | 1 |
| Recording modes: | Manual recording, I/O alarm, SMD recording, smart recording |
| Rtsp url: | rtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main streamrtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Auxiliary stream |
| Scales: | 0.88 kg |
| Search and play back recordings: | Search for recordings by time and type of events. Playback: forward, backward, accelerate, slow downframe by frame |
| Selected features: | The functions are performed in cooperation of the recorder with cameras supporting these functions Advanced perimeter protection functions: intrusion, line crossing with separate rules for vehicles and pedestrians, classification of people and vehicles, face detection, counting people, SMD PLUS - search for an object classified as: human, motor vehicle, non-motor vehicle |
| Snapshot: | Yes |
| Standard: | TCP/IP |
| Storage relative humidity (h-h): | 10 - 93% |
| Storage temperature (t-t): | 0 - 40 °C |
| Supported hard drives: | 1 x 10 TB SATA III |
| Supported languages: | Polish, English |
| Supported network protocols: | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search |
| Supported resolutions: | .max. 8.3 Mpx, 4K UHD - 3840 x 2160 px |
| Switch poe: | Built-in 4-port PoE switch, 25.5 W/Channel-PoE (802.3af/at), max. 36 W (total) |
| Usb: | 2 pcs. USB 2.0 |
| Vga (d-sub) output ports: | 1 |
| Video formats supported: | H.264+, H.265, H.265+, H.264, M-JPEG |
| Video input channels: | 8 channels |
| Video motion detection: | Yes |
| Video outputs: | 1 pc HDMI 4K1 pcs. VGA |
| Video recording modes: | 1080p, 720p |
| Warranty: | 3 years |
| Web access ports: | 80, 37777 |
| Weight: | 860 g |
| Width: | 260 mm |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
