IP DVR: NVR5216-8P-4KS2 (16 CH, 8 POE) DAHUA
€280.61
Shipping from warehouse: D4
Estimated shipping: Mon, Nov 11 - Thu, Nov 14
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- Dahua
- Product code:
- NVR5216-8P-4KS2 / 6939554933233
Share this product:
Specification
| Alarm inputs / outputs: | 4 / 2 |
|---|---|
| Archiving on external media: | Archiving to a USB drive (pendrive, external drive) |
| Audio inputs: | 1 pc CINCH - External microphone input |
| Audio outputs: | 1 pc CINCH |
| Audio support: | 16 Channels - Audio from cameras |
| Bitrate: | .max. 320 Mbps |
| Country of origin: | China |
| Default administrator login / password: | admin / -Administrator password must be set on first run |
| Default ip address: | 192.168.1.108 |
| Dimensions: | 375 x 327 x 53 mm |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Mobile app access port: | 37777 |
| Mobile phone access: | Port: 37777 or cloud access (P2P) Android: Free DMSS app iOS (iPhone): Free DMSS app Watch the video on how to configure P2P in Dahua DVRs and how to enable the mobile application |
| Network features: | Full network support, Remote copying of recordings, Built-in web server |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, PPPoE, IP Filter, FTP, IP Search, Alarm Server, P2P, ONVIF 2.4 |
| Pc app access ports: | 37777 |
| Power: | 100 ... 240 V AC @ 50 / 60 Hz |
| Producer / brand: | DAHUA |
| Ptz rotary head control: | RS-485, PELCO-D/P IP cameras PTZ (Speed Dome) |
| Recording modes: | Manual, alarm, motion detection, scheduling |
| Rtsp url: | rtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main streamrtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Auxiliary stream |
| Scales: | 2.61 kg |
| Search and play back recordings: | Search for recordings by time and type of events. Playback: forward, backward, accelerate, slow downAdvanced search (up to the second) |
| Selected features: | The functions are performed in cooperation with the recorder with cameras supporting these functions Advanced perimeter protection features: intrusion, line crossing with separate rules for vehicles and pedestrians Classification of people and vehicles face detection - supports 6 types of facial attribute extraction Recognizing people based on characteristic elements of the outfit (type of clothing, color of clothing, accessories) counting people estimating the size of the gathered crowd SMD PLUS - search for an object classified as: human, motor vehicle, non-motorized vehicle ANPR - License Plate Recognition heat map Privacy Zones Fisheye-Dewarping - correction of the "fisheye" view to the perspective view |
| Standard: | TCP/IP |
| Supported hard drives: | 2 x 10 TB SATA III |
| Supported languages: | Polish, Bulgarian, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Portuguese, Romanian, Russian, Slovenian, Serbian, Spanish, Swedish |
| Supported resolutions: | .max. 12 Mpx - 4000 x 3000 px |
| Switch poe: | Built-in 8-port PoE switch, 25.5 W/channel, PoE (802.3af/at), max. 130 W (shared) |
| Usb: | 1 pc USB 2.01 pcs. USB 3.0 |
| Video outputs: | 1 pc HDMI 4K1 pcs. VGA |
| Warranty: | 3 years |
| Web access ports: | 80, 37777 |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
