IP DVR BCS-L-SNVR0801-4KE-8P 8 CHANNELS, 8 PoE
€253.38
Shipping from warehouse: D4
Estimated shipping: Fri, Nov 15 - Mon, Nov 18
14 days returnUnconditional return policy
- Availability:
- moderate quantity
- Brand:
- BCS Line
- Product code:
- BCS-L-SNVR0801-4KE-8P / 5904890700178
Share this product:
Specification
| Archiving on external media: | Archiving to a USB drive (pendrive, external drive) |
|---|---|
| Audio inputs: | 1 pc CINCH |
| Audio outputs: | 1 pc CINCH |
| Audio support: | 8 Channels - Audio from cameras |
| Bitrate: | .max. 80 Mbps |
| Country of origin: | China |
| Default administrator login / password: | admin / -Administrator password must be set on first run |
| Default ip address: | 192.168.1.108 |
| Dimensions: | 270 x 205 x 15 mm |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Maximum total load on the switch: | 72 watts (Printing) |
| Mobile app access port: | 37777 |
| Mobile phone access: | Port: 8000 or cloud access (P2P) Android: Free BCS Manager app iOS (iPhone): Free BCS Manager app |
| Network features: | Built-in web server CMS application Live image view, Playback of recordings, Archiving of recordings, remote access |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, Alarm Server, IP Search, P2P, ONVIF |
| Operating temperature: | -10 °C ... 50 °C |
| Pc app access ports: | 37777 |
| Power: | 48 V DC / 1.81 A (power adapter included) |
| Producer / brand: | BCS Line |
| Ptz rotary head control: | IP Speed Dome cameras |
| Recording modes: | Manual, motion detection, scheduling |
| Rtsp url: | rtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main streamrtsp://admin:password o@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Auxiliary stream |
| Scales: | 0.7 kg |
| Search and play back recordings: | Search for recordings by time and type of events. Playback: forward, backward, accelerate, slow downAdvanced search (up to the second)Synchronous playback of all channels, Smart Search |
| Selected features: | The functions are performed in cooperation of the recorder with cameras supporting these functions line crossing intrusion face detection SMD PLUS - search for an object classified as: human, motor vehicle, non-motor vehicle Privacy Areas |
| Standard: | TCP/IP |
| Supported hard drives: | 1 x 10 TB SATA |
| Supported languages: | English, Polish |
| Supported resolutions: | .max. 8.3 Mpx - 3840 x 2160 px 4K UHD |
| Switch poe: | Built-in 4-Port PoE Switch, 25.5W/Channel |
| Usb: | 2 pcs. USB 2.0 |
| Video outputs: | 1 pc HDMI 4K1 pcs. VGA |
| Warranty: | 3 years |
| Web access ports: | 80, 37777 |
Despite our best efforts, we cannot guarantee that the published technical data and photos do not contain inaccuracies or errors, which, however, cannot be a basis for claims.
